ESP-07 WiFi Module (ESP8266)

SKU: HMJ709 Category: Microcontrollers
KSH 600.00
Out of Stock

Product Description

ESP-07 WiFi Module (ESP8266)

Compact SMD Module with Ceramic Antenna and IPEX Connector

The ESP07 is a versatile WiFi module based on the *ESP8266* chip from Espressif [citation:1][citation:6]. This SMD-16 package module comes equipped with an onboard ceramic antenna and features a U.FL/IPEX connector for an external antenna, providing design flexibility for IoT and smart home projects [citation:1][citation:2][citation:8].

802.11 b/g/n WiFi Supports station, softAP, and station+softAP modes [citation:1][citation:6].
Dual Antenna Options - Onboard ceramic antenna + IPEX connector for external antenna [citation:1][citation:2].
Core Processor: ESP8266 Tensilica L106 32-bit MCU [citation:1][citation:4]
Clock Speed: 80 MHz (supports up to 160 MHz) [citation:6]
Flash Memory: 4MB (default) [citation:2][citation:3]

Technical Specifications

ParameterValue
:-:-
Supply Voltage3.0V - 3.6V [citation:2][citation:8][citation:9]
Frequency2.4 GHz ISM band [citation:1][citation:3]
Protocol802.11 b/g/n [citation:1]
PackageSMD-16 [citation:2][citation:6]
Dimensions~21.2 x 16mm [citation:2][citation:8]

*Wi-Fi Output Power* [citation:2]:

  • 802.11b: 16±2 dBm (11 Mbps)
  • 802.11g: 14±2 dBm (54 Mbps)
  • 802.11n: 13±2 dBm (HT20, MCS7)

Pin Configuration

The module features 16 castellated pads [citation:6][citation:9] with key pins including:

PinNameDescription
:-:-:-
5VCC3.3V Power Input [citation:3][citation:9]
1GNDGround
13TXDUART Transmit
12RXDUART Receive
11GPIO0Boot Mode (LOW = Flashing Mode) [citation:3]
7CH_PD/ENChip Enable (HIGH for normal operation) [citation:3][citation:12]
6RSTReset (Active LOW) [citation:3]

! Programmable GPIO & SPI Flash - 9+ GPIO pins and SPI interface for peripherals [citation:1][citation:3][citation:5].

Integrated TCP/IP Stack Full networking support, preflashed with AT command firmware [citation:1][citation:6].

= Applications =

  1. IoT and smart home devices [citation:4][citation:6]
  2. Home automation and industrial wireless control [citation:4]
  3. Wearable electronics and wireless sensor networks [citation:4]
  4. 3D printer WiFi connectivity (BTT boards) [citation:7]
  5. Remote monitoring and control systems
Versatile Interface - Supports UART, SPI, I2C, I2S, PWM, and ADC [citation:1][citation:3].
Low Power Consumption - Deep sleep current as low as 10 µA [citation:1][citation:6].

√ 3.3V logic only - level shifting required for 5V systems [citation:12]

√ AT command support for quick integration

√ SMD package suitable for automated assembly [citation:6]

Troubleshooting

Module not responding:

  • Verify power supply is 3.0-3.6V with >300mA current capability.
  • Check CH_PD/EN is pulled HIGH to 3.3V.
  • Ensure GPIO0 is HIGH for normal boot, LOW for flashing mode [citation:3].

Wi-Fi not connecting:

  • Connect to 2.4GHz network only.
  • Check antenna connection.
  • Verify SSID and password in AT commands.
