Digital Load Cell Weight Sensor HX711 AD Converter Breakout Module 1KG Portable Electronic Kitchen Scale for Arduino Scale

SKU: HMJ780 Category: HIMA electronics
KSH 800.00
Out of Stock

Product Description

Digital Load Cell Weight Sensor Kit 1KG with HX711 Module

Complete Electronic Scale Kit for Arduino Projects

The Digital Load Cell Weight Sensor Kit is a complete solution for building electronic scales and weight measurement projects. This comprehensive kit includes a 1KG load cell, HX711 precision AD converter module, and acrylic round support frames. Perfect for Arduino-based kitchen scales, postal scales, and industrial weight monitoring systems.

Complete kit includes load cell, HX711 module, and acrylic mounting frames
Uses 24bit ADC for highprecision weight measurements
Maximum weight capacity: 1KG - do not exceed rated load

Technical Specifications

ParameterValue
Load Cell Capacity1KG
Load Cell TypeStraight Bar / Beam Type
ADC ModuleHX711
ADC Resolution24-bit
Sampling Rate10/80 Hz (selectable)
Operating Voltage2.7V - 5.5V
Power ConsumptionTypical 1.6mA
InterfaceDigital (Clock + Data)
Weight Accuracy±0.05% FS
Acrylic FrameRound support plates
Dimensions (Board)~38mm x 20mm
Cable Length~300mm

= Key Features =

Complete Kit - Includes load cell, HX711 module, and acrylic frames all in one package

High Precision 24bit ADC for accurate weight readings

Easy Interface Simple twowire connection to Arduino

1KG Capacity - Perfect for kitchen and small weighing applications

Acrylic Frame Professionallooking round support structure included

PlugandPlay - Quick assembly and setup with included hardware

Low Power Ideal for batterypowered projects

Versatile - Works with 3.3V and 5V systems

= Applications =

  • Kitchen scales and food weighing
  • Postal and shipping scales
  • Jewelry and small item weighing
  • Educational weight measurement projects
  • Industrial process monitoring
  • Laboratory experiments
  • Automated dispensing systems
  • Inventory management
  • Portion control systems
  • IoT weight monitoring

Kit Contents

  1. 1KG Load Cell Sensor
  2. HX711 AD Converter Breakout Module
  3. Acrylic Round Support Frames (Top and Bottom plates)
  4. Mounting Hardware (Screws and Nuts)
  5. Connection Cables
All components included for immediate assembly
Only requires Arduino and USB power to complete
Verify load cell direction before final assembly

Wiring Guide

HX711 PinArduino Pin
VCC5V
GNDGND
DTD2
SCKD3
HX711 PinLoad Cell Wire
E+Red
E-Black
A+Green
A-White

> Wire colors may vary - check your specific load cell

Connect E/E to excitation voltage, A/A to signal output

Assembly Instructions

  1. Mount load cell between acrylic plates
  2. Secure with provided screws and nuts
  3. Connect load cell wires to HX711 module
  4. Connect HX711 to Arduino
  5. Power on and calibrate using known weight
  6. Test with various weights for verification
Ensure load cell is properly aligned and level
Use 100g or 200g weight for initial calibration
Do not overtighten mounting screws

Why Choose This Kit?

Complete allinone solution - load cell, HX711, and acrylic frame included
Professional acrylic frame for clean installation
Highprecision 24bit ADC for accurate measurements
Easy to assemble with included hardware
Compatible with all Arduino models
Great value for the price

√ Ready to use out of the box with all components

√ Simple calibration procedure

√ Excellent for DIY and educational projects

√ Durable acrylic construction

√ Reliable HX711 converter

√ 1KG capacity covers most kitchen and small weighing needs

Arduino Test Code

#include "HX711.h" #define DOUT 2 #define CLK 3 HX711 scale; void setup(){Serial.begin(115200);scale.begin(DOUT,CLK);scale.set_scale();scale.tare();} void loop(){Serial.print("Weight: ");Serial.print(scale.get_units(),1);Serial.println(" g");delay(500);}

Calibration Guide

Upload the test code and open Serial Monitor

Place a known weight (e.g., 100g) on the scale

Note the raw reading and calculate calibration factor

Update scale.set_scale() with the calibration factor

Test with different weights for accuracy

Save calibration factor for future use

Calibration factor = known weight / raw reading

For best accuracy, use a weight close to full capacity (e.g., 500g or 1000g)
Calibrate after assembly and before first use

Safety Precautions

Do not exceed 1KG maximum load capacity
Avoid impact or shock loading on the sensor
Keep away from moisture and liquids
Do not twist or bend the load cell
Use on stable, level surface
Calibrate before each use for accuracy
Do not apply load off-center

Handle the load cell with care - it is sensitive to physical stress

Store in dry environment when not in use

Troubleshooting

No reading or zero reading - Check wiring connections and power
Erratic readings - Ensure stable surface and no vibrations
Inconsistent weights - Perform tare and recalibration
Negative readings - Check load cell orientation
Drift over time Allow warmup time for HX711 module

For best results, allow 510 minutes warmup before calibration

Replace load cell if physically damaged

Build your own precision digital scale with this complete kit. Perfect for kitchen use, educational projects, and small industrial applications. All components included - just add Arduino!
