SRA-05VDC-CL 5Pin RELAY

SKU: HMJ652 Category: Relays
KSH 70.00
Out of Stock

Product Description

SRA05VDCCL 5-Pin Power Relay

High-Current SPDT Relay for Arduino & Automation

The SRA05VDCCL is a highperformance 5pin power relay designed for switching heavy loads with a low-power control signal. Featuring a 5V DC coil and SPDT (Single Pole Double Throw) contacts, this relay is ideal for Arduino, ESP32, and industrial automation projects requiring reliable load switching.

5V DC coil with 200mW power consumption
SPDT contacts with 20A switching capacity at 14V DC
Maximum switching voltage: 125V AC - do not exceed

Technical Specifications

ParameterValue
ManufacturerSongle Relay
Coil Voltage5V DC
Coil Resistance125Ω ±10%
Coil Power200mW
Contact Form1C (SPDT - Single Pole Double Throw)
Pin Count5 Pins
Contact Rating20A @ 14V DC
Max Switching Voltage125V AC
Max Switching Current10A
Contact Resistance≤100mΩ
Operate Time10ms
Release Time10ms
Operating Temp-40°C ~ +85°C
Dimensions16 x 12.4 x 14.2mm
MountingThrough-hole PCB

= Pin Configuration (5-Pin) =

PinFunctionDescription
1Coil (+)Positive coil terminal (5V)
2Coil (-)Negative coil terminal (GND)
3COMCommon terminal
4NCNormally Closed (connected to COM when relay off)
5NONormally Open (connected to COM when relay on)

> Coil is nonpolarized no polarity distinction required

NC = connected when relay is OFF, disconnects when ON
NO = disconnected when relay OFF, connects when relay ON

Wiring Guide

# Coil Control

  • Pin 1 (Coil +): Connect to 5V DC
  • Pin 2 (Coil -): Connect to GND

# Load Switching

  • COM (Pin 3): Connect to power source
  • NO (Pin 5): Connect to load (energized when relay ON)
  • NC (Pin 4): Connect to load (energized when relay OFF)
Use flyback diode (1N4007) across coil terminals to protect microcontroller
For inductive loads, use RC snubber circuit to suppress arcs
Maximum switching voltage is 125V AC - do not use for 240V mains

Why Choose SRA05VDCCL?

High 20A contact rating for heavy loads
5V coil for direct Arduino control
Wide operating temperature range
Fast 10ms response time
Non-polarized coil for easy wiring
Compact PCB mount design
Reliable Songle quality

√ Direct connection to Arduino 5V output

√ Excellent for automotive, industrial, and DIY projects

√ Low 200mW coil consumption

√ Clear markings for easy identification

√ Proven reliability in demanding applications

Safety Precautions

Do not exceed 125V AC switching voltage
Ensure load current does not exceed 10A rating
Use flyback diode for inductive loads
Protect from moisture and dust
Keep away from strong magnetic fields
Verify correct wiring before power-up
For mains voltage applications, consult local safety regulations
Use external fuse protection for high-current loads

The SRA05VDCCL is a versatile, highcurrent relay perfect for switching loads in Arduino, automation, and automotive projects. Reliable, compact, and easy to use the ideal choice for your next project.
